All Purpose Repair Unit

all-purpose-repair-unit
All Purpose Rubber Reinforced Repair all purpose rubber reinforced repair units are for use in virtually any application. It is to be used over a filled injury in a bias or radial constructed tire. The all-purpose repair has an extra thick gauge of rubber reinforcement to provide a combination of flexibility with durability for bias and radial tube type or tubeless tires and can be used on all type of inner tubes.

All Purpose Repair Unit

Part Number Product
Name
Repair Unit Ø Injury Size Ø Recommended
Stem Insert
Qty/
Box



Boxes/
Carton





Tube Injury Passenger / LT
Tire Injury
MM Inches MM Inches MM Inches Inches
3-330 AP C 45 R 45 1 3/4 20 3/4 3 1/8 SI 06 W 30 20
3-330X AP C 45 R (1000) 45 1 3/4 20 3/4 3 1/8 SI 06 W 1000 1
3-331 AP C 55 R 55

2 1/4

30 1 1/4 3 1/8 SI 06 W 30 18
3-331X AP C 55 R (1000) 55 2 1/4 30 1 1/4 3 1/8 SI 06 W 1000
3-332 AP C 65 R 65 2 1/2 40 1 1/2 6 1/4 SI 08 W 25 18
3-332X AP C 65 R (1000) 65 2 1/2 40 1 1/2 6 1/4 SI 08 W 1000 1
3-333 AP C 75 R 75 3 1/4 50 2 6 1/4 SI 08 W 30 20
3-333X AP C 75 R (500) 75 3 1/4 50 2 2/3 6 1/4 SI 08 W 500 1
3-334 AP C 85 R 85 3 3/8 60 2 2/3 10 3/8 SI 10 W 30
3-334X AP C 85 R (500) 85 3 3/8 60 2 2/3 10 3/8 SI 10 W 500 1
3-340 AP S 45 R 45 1 3/4 20 3/4 3 1/8 SI 06 W 30 20
3-340X AP S 45 R (1000) 45 1 3/4 20 3/4 3 1/8 SI 06 W 1000 1
3-341 AP S 55 R 55 2 1/4 30 1 1/4 3 1/8 SI 06 W 30 118
3-341X AP S 55 R (1000) 55 2 1/4 30 1 1/4 3 1/8 SI 06 W 1000 1
3-342 AP S 65 R 65 2 1/2 40 1 1/2 6 1/4 SI 08 W 25 118
3-342X AP S 65 R (1000) 65 2 1/2 40 1 1/2 6 1/4 SI 08 W 1000 1
3-343 AP S 75 R 75 3 1/4 50 2 6 1/4 SI 08 W 30
3-343X AP S 75 R (500) 75 3 1/4 50 2 6 1/4 SI 08 W 500 1
